SPECIFICATION
General Description CD Player, DAC, Pre-Amp with Integrated amplifier
Key Technology & Features DSD (up to DSD256 Compatible) / Bluetooth (aptX)
DTS Play-Fi Technology
Audio File Formats ALAC, WAV, FLAC, AIFF, WMA, MP3, AAC, AACHE,
AAC+, DSD64, DSD128, DSD256
D/A Converter ESS ES9018 32bit DAC
USB Input USB B (PC / MAC)
Digital Audio Inputs 2 x Optical TOSlink, 2 x RCA (DIG1, DIG2)
Digital Audio Outputs 1 x Optical TOSlink, 1 x RCA (DIG)
Analogue Inputs 2 x RCA (AUX1, AUX2)
Analogue Outputs 2 x RCA, 2 x Balanced XLR, 6.3mm HeadphoneJack
Speaker Outputs 1 Pair Speaker Terminals
Sample Rate (USB B) 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz,192kHz, 384kHz
Sample Rate 44.1 – 192kHz (Digital Inputs / Outputs)
Standby Power Consumption <0.5W
Pre-Amplifier Section
Output Level (1kHz) Variable Output RCA 0-2.3 Vrms / XLR 0-4.6 Vrms
Frequency Response 20Hz-20kHz, 1kHz (± 0.2dB)
Total Harmonic Distortion < 0.002% (@1KHz, BW=20Hz-20kHz)
Signal to Noise Ration(S/N) > 110dB (A-weighted, ref. 1V)
Channel Separation >100dB (1kHz)
Power Amplifier Section
Rated Power Output 2 x 75W (8Ω)
Frequency Response ± 0.5dB (20Hz-20kHz, 1kHz)
Total Harmonic Distortion < 0.003% (@1KHz, 50W/8Ω, BW=20Hz-20kHz)
Signal to Noise Ration(S/N) > 108dB (A-weighted, ref. 75W)
Channel Separation >82dB (A Weighted, ref.1W)
Dynamic Range A-wtd >98dB
Power Requirement 220V-240V~50-60Hz
(depending on region) 100V-120V~50-60Hz
Dimensions & Weight
Dimensions (Unpacked) 320 x 320 x 105mm
Dimensions (Packed) 465 x 465 x 220mm
Net Weight 11.5 kg
Gross Weight 13.8 kg
